Benchtop meter inoLab® Cond 7310

  • SKU: 1CA300
Request a Quote
  • Description


    Precise and high performance laboratory conductivity meter with GLP supportung functions for documentation measuring results

    •Convenient and safe operation via plain text menus
    •Documentation of all data via USB interface or optional built-in printer - fast and error-free
    •Suitable for measurements according pharmacopeia
    The new inoLab® Cond 7310 is highly suitable for all conductivity precision measurements connected with automatic documentation according to GLP/AQA in quality labs in all industries. It works with all modern WTW conductivity measuring cells to cover all applications. For the documentation, the serial number of the used sensor can be entered. Upon request, the measured values can be put out via the optional built-in printer.
    •Repeatable measuring results by active, automatic AutoRead function with automatic recognition of stable values
    •The sensor symbol informs about the status of the electrode
    •Graphic display with plain text menus for the convenient and safe operation
  • Specifications
    Parameter Conductivity/Salinity/spec. resistivity, TDS
    Conductivity 0.001 µS/cm ... 1000 mS
    spezischer Widerstand 0.00 ... 199 MOhm cm
    Salinity 0.0 ..70.0
    TDS 0 ... 199.9 g/l
    Temperature -5.0 ... 105 °C
    Resolution Conductivity 0.1 µS/cm
    Salinity 0.1
    Accuracy Temperature +/- 1 digit 0.1 K
    Accuracy Messwerte +/- 1 digit +/- 0.5 %

Downloads

  • Manual

    Cond 7310 (P) (German)

    Laborgerät,
    Bedienungsanleitung

    Cond 7310 (P) (English)

    Laboratory meter,
    Operating manual

    Cond 7310 (P) (French)

    Laboratory meter,
    Operating manual

    Cond 7310 (P) (Spanish)

    Laboratory meter,
    Operating manual
  • Brochure
  • Software

    inoLab 7310, 7320 - Firmware Update - V1.26

    Recommendation: Because of continuous improvement of internal performance we always recommend using the latest firmware version.

    This update solves a problem in the calibration history. Please note: When installed except the current calibration the history will be deleted, if necessary, please make a copy!
    Firmware version after successful update:

    pH 7310 V1.18
    pH/ION 7320 V1.09
    Oxi 7310 V1.18
    Cond 7310 V1.20

    Download and installation notes:

    The necessary cable for connection to PC via serial interface is included in the inoLab® set.

    Version history – innovations

    •V.1.26: Various optimizations
    •V1.25: Various optimizations
    •V1.24: This update solves a problem in the calibration history. Please note: When installed except the current calibration the history will be deleted, if necessary, please make a copy!
    •V1.23: Smaller debugging
    •V1.22: Various optimizations for inoLab® Cond 7310
    •V1.21: Optimization of AutoRead function

    MultiLab Importer-Setup32

    Software

    Version history – innovations

    V 1.25: MultiLab Importer (Excel Add-In for acquisition of measured data)

    • Allows measurement and data entry of barcoded sample-ID via PC-connected barcode Reader for Turb® 750, Turb 430® and photoFlex® Series

    V 1.24: MultiLab Importer (Excel Add-In for acquisition of measured data)

    • New: Includes now photometers and turbidity meter of pHotoFlex series, Turb 430 and Turb 750 models
    • General improvements

    V1.23: Enhancements for MultiLab Importer

    • New Download of OxiTop®-IDS measurement date possible (results and measurement parameters)
    • Enhancement at transfer of electrochemical measurement results.

    MultiLab Importer-Setup64

    Software

    Version history – innovations

    V 1.25: MultiLab Importer (Excel Add-In for acquisition of measured data)

    • Allows measurement and data entry of barcoded sample-ID via PC-connected barcode Reader for Turb® 750, Turb 430® and photoFlex® Series

    V 1.24: MultiLab Importer (Excel Add-In for acquisition of measured data))

    • New: Includes now photometers and turbidity meter of pHotoFlex series, Turb 430 and Turb 750 models
    • General improvements

    V1.23: Enhancements for MultiLab Importer

    • New Download of OxiTop®-IDS measurement date possible (results and measurement parameters)
    • Enhancement at transfer of electrochemical measurement results.

    VCP driver MultiLine, inoLab, ProfiLine, HandyLab and Lab

    Update File for Win 7 and 8

    MultiLine 3620, 3630, 3510.

    inoLab Multi 9630, 9620, 9310

    ProfiLine 33x0

    inoLab 73x0

    HL 600, HL 680

    Lab 865, Lab 955, Lab 875, ProLab 2500

    Driver for communication between meters with an USB 1.1. interface and a PC, Windows® 7 and 8. Please check for 32/64 bit system.

    VCP driver MultiLine, inoLab, ProfiLine, HandyLab and Lab

    Update File for Windows 10

    MultiLine 3620, 3630, 3510.

    inoLab Multi 9630, 9620, 9310

    ProfiLine 33x0

    inoLab 73x0

    HL 600, HL 680

    Lab 865, Lab 955, Lab 875, ProLab 2500

    Driver for communication between meters with an USB 1.1. interface and a PC, Windows® 10. Please check for 32/64 bit  system.
