MultiLab® Pro IDS: GxP-compliant multi-parameter measuring device for up to four simultaneous measurements

The new MultiLab® Pro IDS has the following features that the inoLab® did not have before:

• GxP-compliant with different output formats
• Touchscreen with graphical user interface
• With the MultiLab® Pro 40 IDS: 4 measuring channels
• Smaller dimensions

• The new MultiLab® Pro has the following dimensions: 197 x 161 x 70 mm
• The inoLab® has the following dimensions: 285 x 255 x 80 mm
• You save up to 3 measuring devices

Direct size comparison:

Analog:

You can continue to use your analog S7 plug head pH and redox electrodes with an adapter cable analog/IDS pH electrodes. A special adapter will soon be available for analog sensors with temperature probes.

Digital:

You can use all digital sensors with the above parameters (pH, ORP, conductivity, turbidity and oxygen).

Digital plug-in head sensors:

You can use all digital plug head sensors with the named parameters (pH, redox, conductivity, turbidity and oxygen).

No, you can measure all of these parameters with our MultiLab® Pro IDS - no additional module or software is required.

• You can connect all intelligent digital sensors (IDS)
• Analog pH and redox electrodes with an S7 plug-in head can be connected via an adapter (adapter cable analog/IDS pH electrodes)

• The MultiLab® Pro IDS is perfect for wireless measurement.
• We use a Bluetooth® connection for secure signal transmission

The device can be connected to a standard Vesa connection using the existing holes on the back.

• 1 x USB-C for power supply and data transfer (is then taken over by the PC or hub)
• 2 x USB-A for peripheral devices

The MultiLab® Pro IDS can be operated via the USB-C connection with a power bank (min. 15 W at 5 V).

Yes, a USB-C power supply unit is included in the scope of delivery.

Safe and convenient operation also includes a modern anti-glare display.

IDS stands for “Intelligent Digital Sensors”. Our IDS sensors do not transmit the measured analog values to a measuring device, but convert the analog signals directly in the sensor into digital values. This is done by a miniaturized measuring device located in the sensor head. Direct conversion in the sensor prevents interference and guarantees fail-safe data transmission. The subsequent digital transmission of the measured values means that cables with a length of up to 100 meters are possible.

Our IDS sensors are available either with a fixed cable or with a plug-in head. Either various cables can be connected to an IDS plug-in head electrode or radio modules, which enable wireless measurement.

In addition to the measured data, the sensor name, sensor serial number, calibration status and additional data such as cell constants and temperature compensation (for conductivity cells) and correction data for the membrane (for optical oxygen sensors) are transmitted to the measuring device and GxP-compliant data acquisition is fully supported.

More Information about Xylem's IDS System can be found here:

IDS System

Technology with Responsibility: With the Eco-friendly label, Xylem Analytics demonstrates that sustainability and technology go hand in hand. Our products make a measurable contribution to resource conservation, support customers in achieving their ESG goals, and serve as a visible symbol of responsibility – for the environment, users, and future generations.

That commitment starts right now, with the introduction of the MultiLab® Pro IDS. A high-performance multi-parameter device with up to 4 galvanically isolated measuring channels – the first product to carry our Eco-friendly symbol. Designed to be compact and efficient the MultiLab® Pro IDS was built with sustainability in mind.

More Information about our Eco-friendly label.

MultiLab® Pro IDS enables GxP-compliant export of your measurement data in CSV format. Navigate to the data export options in the menu and select the CSV format. The exported file contains all relevant measured values, sensor information, calibration data, and timestamps.

How do I open a CSV file in Excel?

There are two methods for opening your MultiLab® Pro IDS CSV data in Excel:

Option 1: Import wizard (recommended for precise control)

1. Open Excel with a blank workbook.
2. Go to “Data” → “Get Data” → “From File” → “From Text/CSV.”
3. Select your CSV file.
4. In the preview window, you can check the delimiter (usually a semicolon or comma) and the encoding.
5. Click “Load” to import the data.

Option 2: Direct opening (old versions prior to Microsoft 365)

1. Open Microsoft Excel.
2. Click on “File” → “Open.”
3. Select “All Files” from the drop-down menu (not just Excel files).
4. Navigate to your CSV file and open it.
5. Excel automatically recognizes the CSV format and displays the data in columns.

Why is my data displayed in a single column?

This is usually due to an incorrect separator. MultiLab® Pro IDS uses the semicolon (;) as the default separator. If Excel expects a comma, all data will be displayed in a single column.

Solution:

1. Go to “Data” → “Text to Columns”
2. Select “Delimited” and click “Next”
3. Activate “Semicolon” as the separator
4. Click on “Finish”

How do I keep the decimal separators correct?

MultiLab® Pro IDS uses the period (.) as the decimal separator. If your Excel version is set to German format and expects a comma, measured values may be interpreted incorrectly.

Solution:

1. Select the columns containing the measured values.
2. Click on “Data” → “Text to Columns.”
3. Select “Delimited” and click “Next” twice.
4. In the last step, click on “More” and set the period as the decimal separator.

How do I save my data as an Excel file?

After successfully importing your CSV data:

1. Click on “File” → “Save As.”
2. Select “Excel Workbook (*.xlsx)” as the file type.
3. Enter a meaningful file name.
4. Save the file in the desired location.
5. Your measurement data remains GxP-compliant, as all original information from the MultiLab® Pro IDS is retained.

Can I import multiple CSV files at the same time?

Yes, you can merge multiple measurement series into one Excel file:

For individual spreadsheets:

Import each CSV file into a new spreadsheet via “Data” → “Get Data.”

For a continuous table:

1. Use the function “Data” → “Get Data” → “Combine New Query.”
2. Select “Append” and add multiple CSV files.

Is any information lost during conversion?

No, if the import is done correctly, all data recorded by the MultiLab® Pro IDS is retained, including:

• Measurement values for all parameters (pH, conductivity, oxygen, etc.)
• Sensor designation and serial number
• Calibration status and calibration data
• Time stamp
• Temperature compensation data
• All other GxP-relevant metadata

How can I further process the data after import?

After importing into Excel, all Excel functions are available to you:

• Create charts to visualize your measurement curves
• Calculate mean values, standard deviations, and other statistical parameters
• Filter and sort your data according to various criteria
• Create GxP-compliant reports with all relevant sensor information

Which version of Excel do I need?

CSV import works with all common versions of Excel:

• Excel 2016 and newer (recommended)
• Excel 2013
• Excel 2010
• Excel for Microsoft 365

The menu names may vary slightly depending on the version.
