Turbidimeter Turb® 750 IR

Turbidimeter Turb® 750 IR

  • SKU: 600120
Request a Quote
  • Description

    NEW: Sample-ID via Barcode

    Download-Software

    WTW Turb® 750 IR fulfills the demands of many lab and industrial applications for a AQA supported turbidity measurement up to 1100 FNU/NTU. With the Intelligent Reproducibility and Plausibility-Check (IRPC) reliable findings are proven.

    Measurement conforming to standards in drinking water, lab and industrial applications.

    WTW Turb® 750 IR measures nephelometrically according to DIN EN ISO 7027-1 up to 1100 NTU/FNU with AQA support and PC documentation:

    • Well proven WTW® optics with fast data output
    • Multiple measurement and data evaluation with Intelligent Reproducibility and Plausibility Check (IRPC)
    • Bench-saving despite comprehensive functionality
    • Invincible price-/performance ratio

    Turbidity stands for an indicator parameter on quality in drinking water, waste water process and many industrial applications. The measurement is support by:

    • Measurement procedure fulfilling DIN EN ISO 7027-1 *)
    • Function keys
    • Comfortable menu-guided 3-point standard calibration
    • Flexible calibration with 2-5 user-defined calibration points
    • QuickCAL: 1-point-calibration at 10 NTU
    • AQA, calibration interval and records with PC-documentation

    *) For drinking water measurement acc. to  US EPA 180.1 Turb® 750 T is the appropriate instrument.

    More informationen in: "Turbidity An interesting parameter - Brief Overview, Measurement Tips & Tricks" and
    in our video: "https://www.youtube.com/watch?v=UW4Mk0IrOww"

  • Specifications
    Light source  LED  830-890 nm acc. to DIN EN ISO 7027-1
    acc. to standard methods DIN EN ISO 7027-1, DIN 38404
    Modes Nephelometric (scattering 90°)
    Display Backlit graphics display 160x104
    Keypad Foil keypad with tactile feedback alphanumeric entry option
    Range 0-1100 FNU/NTU
    Units FNU/NTU
    Resolution (Measurement resolution max. 0,02 NTU due to natural scattering of water; digital resolution >0,02 if optional ) 0,01 for 0,00 -9,99, 0,1 for 10 – 99,90, 1 for 100 - 1100
    Accuracy NTU/FNU 0.01 NTU/FNU or +/- 2% of finding
    Repeatability < 0.5% of finding
    Reading modes Findings with Intelligent Reproducibility and Plausibility Check (IRPC),
    rapid settlement samples supported by quick response time and IRPC
    Response time 4 sec
    Calibration - options Automatic 3-P Kal, (Default),  2-5 P user calibration, QUICKCal
    Calibration protocol and interval setting yes / yes
    AQS-Support Calibration protocol and interval setting, AQA flag, Cal flag
    Data storage 2500 data sets with Cal protocol, AQA flag, GLP comliant data management with LIMS-connection
    Sample Identification yes - alphanumeric
    Air Purge no
    Firmware-Update yes via USB
    Interface RS 232, USB, Printer via PC or RS232
    Storage condition instrument  - 25 °C ... + 65 °C (13-149 °F)
    Operating Temperature Range +5 °C ... +55 °C (41-131 °F) with power plug connected: +5 °C ... +40 °C  (41-104 °F)
    Data management GLP-compliant incl. PC software USB, RS232 Turb® Data
    Dimensions (H x W x D) ca. 290 x 190 x 80 mm
    Weight 1,1 kg
    Calibration Standards Longterm stable Cal.Kits for standard 3-P calibration; 0,02-10-1000; FNU/NTU; Polymer AMCO® Clear standards: longterm stability, higly precise, optimized to optics, production accuracy ± 1%,  non-hazardous
    Vials , Sample Volume Vials 28 mm diameter, volume min. 15 ml; Borosilicate, cap: phenolic resin, PTFE coated sealing gasket.; NO SILICON OIL to cover scratches required for measurement procedure!
    Sample conditions sample temperature < 70°C (158°F)
    Power supply Wide range power supply with plugs for Euro, US, UK and Australia
    Certificates CE
    Delivery Lab turbidimeer Turb® 750 IR; 4 batteries 1,5 V Typ AA; Wide range power supply; cable USB-A to USB-B mini; 6 empty vials, sticker for orientation marking; Cal.Kit Turb® 430/750 IR; Cloth, quick guide, compact operation manual, CDROM with extended manual, CDROM with PC software Turb® Data; Inspection protocol

Downloads

  • Software

    MultiLab Importer-Setup32

    Software

    Version history – innovations

    V 1.25: MultiLab Importer (Excel Add-In for acquisition of measured data)

    • Allows measurement and data entry of barcoded sample-ID via PC-connected barcode Reader for Turb® 750, Turb 430® and photoFlex® Series

    V 1.24: MultiLab Importer (Excel Add-In for acquisition of measured data)

    • New: Includes now photometers and turbidity meter of pHotoFlex series, Turb 430 and Turb 750 models
    • General improvements

    V1.23: Enhancements for MultiLab Importer

    • New Download of OxiTop®-IDS measurement date possible (results and measurement parameters)
    • Enhancement at transfer of electrochemical measurement results.

    MultiLab Importer-Setup64

    Software

    Version history – innovations

    V 1.25: MultiLab Importer (Excel Add-In for acquisition of measured data)

    • Allows measurement and data entry of barcoded sample-ID via PC-connected barcode Reader for Turb® 750, Turb 430® and photoFlex® Series

    V 1.24: MultiLab Importer (Excel Add-In for acquisition of measured data))

    • New: Includes now photometers and turbidity meter of pHotoFlex series, Turb 430 and Turb 750 models
    • General improvements

    V1.23: Enhancements for MultiLab Importer

    • New Download of OxiTop®-IDS measurement date possible (results and measurement parameters)
    • Enhancement at transfer of electrochemical measurement results.

    Turb® Data – PC-Software for data management of the turbidimeter series Turb 750 IR/T – V5.03 (English)

    • GLP compliant data transfer in CSV formate
      Instrument recognition and user name
      Data import into Excel
      Data import into LIMS
      Cable USB-Mini – USB-A in delivery of Turb® 750

    Download- and installation instructions:
    Unzip and open the file and follow the instructions

    System requirements:
    Microsoft® Windows 7, Windows 8, Windows 10

    Turb 750 IR/T – Firmware Update V2.84

    Attention: the data storage of versions below V2.84 are not compatible and will be deleted: Please save you data before update!

    By enhancing ID to 12 digits with alphanumeric definition, the former ID structure cannot be kept and existing measurement data will be deleted.

    Version History:


    Turb® Data – PC-Software for data management of the turbidimeter series Turb 750 IR/T – V5.03 (English)

    Download- and installation instructions:
    Unzip and open the file and follow the instructions

    System requirements:
    Microsoft® Windows 7, Windows 8, Windows 10

    V2.84

    • GLP compliant data transfer in CSV formate
    • Instrument recognition and user name
    • Data import into Excel
    • Data import into LIMS
    • Cable USB-Mini – USB-A in delivery of Turb® 750
    • User control: Reset Admin deletes any structure created by MultiLab User from the EEPROM ("factory settings").

    V2.80 – 2.83

    • New menu item "Factory settings" added
    • Cal-LOT is deleted from the system on reset
    • New language Chinese


    V2.80

    • User administration settings via cost-free MultiLab User PC-Software
    • 3 user class definitions Admin, User, Guest (for AQA, CAL, delete data....)
    • Lot number entry for standards
    • New 5-P calibration option "PharmaCal" according to pharmacopoeia for clarity-turbidity measurement
    • AQA with 5 Standards
    • Lot number entry for AQA standards
    • values in EBC unit

    V2.66

    • Alphanumeric ID including special characters , 12 digits
    • Auto-Print for connected printers
    • Auto-Print into opened terminal and LIMS programs

    MultiLab User - Software Update V2.00

    MultiLab User (PC-Software) for generation of User Administration for following devices: Turb ® 750 Serie and Multi 3630 IDS, Multi 9630 IDS, Multi 3620 IDS, Multi 9620 IDS, Multi 3510 IDS and Multi 9310 IDS.

    No administration rights required.
    Requirements: Win 10, free USB connecion or USB-Hub (USB driver)
    Version: V2_00
    Installation: Unzip "Install_MulitLabUser_V2-00.zip" and install by following on-screen instructions

    Turb 750 IR/T - Software Update V 5.03 Spanish

    Turb® Data - Software para PC para la gestión de datos de la serie de turbidímetros Turb® 750 - Versión 5.03 (Español)

    • Transferencia de datos en formato CSV conforme a GLP
    • Reconocimiento del instrumento y nombre de usuario
    • Importación de datos a Excel
    • Importación de datos a LIMS
    • Cable USB-Mini - USB-A en el suministro del Turb® 750

    Instrucciones de descarga e instalación:

    Descomprima y abra el archivo y siga las instrucciones

    Requisitos del sistema:

    Microsoft® Windows 7, Windows 8, Windows 10

    Turb 750 IR/T – Firmware Update V5.03 French

    Turb® Data - Logiciel PC pour la gestion des données des turbidimètres de la série Turb® 750 -  V5.03  (français)

    • Transfert de données conforme aux GLP en format CSV
    • Reconnaissance de l'instrument et du nom de l'utilisateur
    • Importation des données dans Excel
    • Importation des données dans LIMS
    • Câble USB-Mini - USB-A dans la livraison du Turb® 750

    Instructions de téléchargement et d'installation :

    Dézippez et ouvrez le fichier et suivez les instructions.

    Configuration requise:

    Microsoft® Windows 7, Windows 8, Windows 10

  • Manuals
  • Flyers / Brochures / Catalogues

    Turb 750 (Flyer, English, 999298US)

    Flyer, 8 Pages, English, 999298US,
    "Lab turbidimeter with IRPC - the intelligent value check"

    Turb 750 (Flyer, German, 999298D)

    Flyer, 8 Seiten, German, 999298D,
    "Labor-Turbidimeter mit intelligentem Messwert-Check IRPC"

  • Application Reports / Case Studys

    Turbidity An interesting parameter - Brief Overview, Measurement Tips & Tricks

    Turbidity An interesting parameter,
    Brief Overview, Measurement Tips & Tricks,
