| Measuring input 1 (analog) |
pH/mV-input with 24 bit transducer. Electrode socket according to DIN 19 262 or BNC with RFID receiver for SI Analytics ID electrodes |
| Measuring range pH/accuracy |
- 3.0… 18.00 / 0.002 +/- 1 digit |
| Measuring range mV/accuracy |
- 2000…2000/ 0.1 +/- 1 digit |
| Measuring input µA: |
μA-connector for double platinum electrodes, connection: 2 x 4 mm - sockets), polarisation voltage variably adjustable |
| Measuring input temperature: |
Connector for Pt 1000 / NTC 30 KOhm ( connection: 2 x 4 mm - sockets) |
| Measuring range temperature |
Pt 1000 - 75…195 °C / NTC 30 KOhm - 40 …125 °C |
| Measuring input: (digital), IDS |
Digital input for teh connection of IDS®-sensors (pH, mV, conductivity)/ accuracy depends on teh connected sensor |
| pH |
0.000…14.000+/- 0.004 |
| mV |
+/- 1200 +/- 0.2 |
| Temperature °C |
- 5.0…105 +/- 0.2 |
| Conductivity |
0.00…2000 mS/cm +/- 0,5% from measurement value |
| Interfaces: |
3 × USB (2 x USB-A and 1 × USB-B), 2 × RS-232-C and 1 x LAN |
| Interchangeable burettes |
5, 10, 20 ml or 50 ml intelligent interchangeable burette head |
| Resolution (Steps): |
20.000 steps |
| Dosing accuracy: |
according to DIN ISO 8655, part 3:
accuracy: < 0.15 %
precision: < 0.05 - 0.07 % (in dependence of the used burette size) |
| Display |
3.5 inches - 1/4 VGA TFT graphic color display with 320 x 240 pixels |
| Housing material |
Polypropylene |
| Dimensions |
15.3 x 45 x 29.6 cm (W x H x D), height with interchangeable head |
| Front keyboard |
Polyester coated |
| Material interchangeable burettes |
Valve: PTFE/ETFE;
Cylinder: borosilikate glass 3.3 (DURAN®)
hoses (FEP, blue) |
| Weight |
2.3 kg for basic device, 3.5 kg für complete device with interchangeable head (with empty reagent bottle) |
| Ambient conditions |
Ambient temperature: + 10 ... + 40 °C for operation and storage Humidity according to EN 61 010, Part 1: max. relative humidity 80 % for temperatures up to 31 °C, linear decrease down to 50 % relative humidity at a temperature of 40 °C |
| Power supply: |
100-240 V; 50/60 Hz, power input: 30 VA |
| CE-sign: |
EMC compatibility according to the Council Directive: 2004/108/EG; applied harmonized standards: EN 61326-1:2006
Low-voltage directive according to the Council Directive 2006/95/EG Testing basis EN 61 010, Part 1 |
